Prefabricated Folding Flat Pack Luxury 20ft Movable Foldable Modular

Luxury 20ft Movable Foldable Modular Prefabricated Flat Pack Cheap Folding Flat Pack Container House

imension6055*2438*2896mm
Roof main frame2.0~3.0mm, SGH340, Galv. with electrostatic spraying
Roof sub-frameC90&Sq. 25, 1.2~2.0mm, Galv. with electrostatic spraying
Floor main frame2.0~3.0mm, SGH340, Galv. with electrostatic spraying
Floor sub-frameC120, 1.8~3.0mm, Galv. with electrostatic spraying
Corner pillar2.0~3.0mm, SGH340, Galv. with electrostatic spraying
Lift corner piece6mm corner cast
Roof covering plate0.5mm galv. Metal steel sheet
Roof insulation75mm fiberglass with aluminum foil, density=14kg/m3
Roof suspended ceiling0.45mm galv. Metal sheet
Floor bottom covering plate2.5mm Polycarbonate Sheet,high Weather resistance and impact resistance
Floor insulation(optional)75mm fiberglass with aluminum foil, density=14kg/m3
Floor board18mm fiber cement plate
PVC flooring1.6mm heavy-duty vinyl leather
Wall panelDual-sided Galv.steel sheet 0.3/0.3mm & 0.4/0.4mm with coating, 50mm/75mm/100mm EPS/fiberglass/rockwool/PU insulated sandwich panel
WindowPVC double-glazed glass sliding window with mosquito screen &security fence
Electrical SystemIncluding PDB/industrial plug/socket/switch/lamp
Rain drainage pipe¢50mm PVC pipe
customized service and personalized design are welcomed!!

WHAT'S FLAT PACK?
Lanjing flat pack container is the modular industrial prefabricated system, comprising Roof, Floor, Pillars and Wall panels (with doors/windows). Lanjing flat pack container's dimension conform to ISO shipping container (20ft), the Roof Floor is prefabricated ready in Lanjing factory. While it's transportation, Lanjing will take the "ALL IN ONE PACKAGE" solutions, which means all the components of one modular container house will be packed in one Flat pack, including 1 Roof, 1 Floor, 4 Pillars, All wall panels (including doors windows) and all the other related accessories.
4 pcs Flat pack units could be combined as one bundle, and the dimension is same as ISO shipping container, with ISO standard corner casts, are easy for transportation and crane lifts during the shipment.
Further to the Flat pack transportation solutions, the flat pack container house could be loaded in to 40ft HQ shipping containers, which quantity will be 6 units per 40ft HQ shipping container. Lanjing Flat pack container house system could be combined in both horizontal and vertical, also could be stacked up to Max. 3floors, to make more large space for multi-purpose usage.
